The machine uses the most advanced anti-high dust electronic counting technology. Tablets (including shaped tablets), hard capsules, soft capsules (transparent, opaque) pellets, and other solid particles ranging in size from 3 to 12 mm can be counted and dispensed. Can be bottled, boxed, bagged. Fully compliant with GMP requirements, especially suitable for research institutions, hospitals, new small pharmaceutical factories, health products factories.
Main features
1 Strong compatibility,It can count and bottle various kind of solid preparation or solid granules for example,tablet ,capsule,soft capsule(transparent and non-transparent),pill etc.
2 Vibration cutting: channel vibration under homogeneous materials, unique patent agencies blanking, turning out material is steady,not damage
3 Anti high dust :Adopting the anti high dust photoelectric sensing technology only developed by our company ,it also can work stably under the high dust circumstance.
4 Correct counting :With automatic photoelectric sensor counting ,the error of bottling is less than nation standard Special structure of the discharge spout, can prevent blocking drugs, small bottle can fast bottling (optional)
5 High intelligence :It has various alarm and control functions like no bottle no count, check fault automatically and so on.
Details
Step 1
Contact power
(voltage 110v /220v/240v/208v/415v)
open the switch
Step 2
Put capsule or tablet or softgel in the bucket and wait for it to start
Step 3
open touch screen display ,set the required speed /output and other parameter you need
Step 4
test multi-stage vibration separation device ,effective separation and counting of multipe sizes ,irregular, and viscous materials
Step5
customized feed nozzle, filling count for many types of bottles
| Main Technical Data |
| Model | LTEC-12 | LTEC-16 | LTEC-24 | LTEC-32 |
| Slide wheel | 12 Channels | 16 Channels | 24 Channels | 32 Channels |
| Size of Object | Tablet: φ5-12mm Capsule: 00#-5# all kinds of soft capsule |
| Size of bottles | 20-300ml |
| The diameter for bottles mouth | 20-80mm |
| Output | 4,000pcs/min | 6,000pcs/min | 8,000pcs/min | 10,000pcs/min |
| Capacity | 40bottles/min | 60bottles/min | 80bottle/min | 100bottles/min |
| Power | 0.9KW | 0.9KW | 1.35KW | 1.35KW |
| Power supply | 220V 60HZ |
| Air pressure | 6kgs/c |
| Overall dimensions(mm) | 1700×1700×1900 | 2000×1700×1900 | 2800×1700×1900 | 3200×1700×1900 |
